Production-Grade Docker Deployment: A 2025 Architect's Guide

Written from 15+ years of experience deploying containerized systems at scale across fullstack, AI/ML, IoT, and robotics domains

After architecting containerized deployments for everything from high-frequency trading platforms to autonomous robot fleets, I've learned that production Docker deployments require far more than just writing a Dockerfile. This comprehensive guide distills hard-won lessons from real-world deployments into actionable strategies for 2025 and beyond.

Table of Contents

1. Modern Multi-Stage Build Patterns
2. Security-First Container Design
3. Health Checks and Self-Healing
4. Environment Configuration & Secrets
5. Production Logging & Observability
6. Orchestration: Kubernetes vs Docker Swarm
7. Domain-Specific Deployments
   • Fullstack Applications
   • AI/ML Model Serving
   • IoT & Edge Computing
   • Robotics Systems (ROS/ROS2)
8. Scaling Architecture Patterns
9. CI/CD Integration & GitOps
10. Monitoring & Troubleshooting
11. Future-Proofing Your Deployments

Modern Multi-Stage Build Patterns {#modern-multi-stage-builds}

Multi-stage builds are no longer optional—they're fundamental to production deployments. Here's why and how to use them effectively:

The Problems Multi-Stage Builds Solve

1. Image Bloat: Development dependencies shouldn't ship to production
2. Attack Surface: Build tools are unnecessary security risks in runtime
3. Reproducibility: Separate build from runtime for consistent deploys

Production-Ready Multi-Stage Pattern

 Copy
# ========================================
# Stage 1: Build Environment
# ========================================
FROM node:20-alpine AS builder

# Install build dependencies only
RUN apk add --no-cache python3 make g++

WORKDIR /build

# Layer caching optimization: Copy dependency files first
COPY package*.json ./
COPY yarn.lock* ./

# Install ALL dependencies (including devDependencies)
RUN npm ci

# Copy source code
COPY . .

# Build application
RUN npm run build && \
    npm prune --production

# ========================================
# Stage 2: Production Runtime
# ========================================
FROM node:20-alpine

# Security: Create non-root user
RUN addgroup -g 1001 -S nodejs && \
    adduser -S nodejs -u 1001

# Install only runtime dependencies
RUN apk add --no-cache dumb-init

WORKDIR /app

# Copy only production artifacts
COPY --from=builder --chown=nodejs:nodejs /build/dist ./dist
COPY --from=builder --chown=nodejs:nodejs /build/node_modules ./node_modules
COPY --from=builder --chown=nodejs:nodejs /build/package.json ./

# Switch to non-root user
USER nodejs

# Use dumb-init for proper signal handling
ENTRYPOINT ["dumb-init", "--"]

# Health check
HEALTHCHECK --interval=30s --timeout=3s --start-period=40s --retries=3 \
    CMD node -e "require('http').get('http://localhost:3000/health', (r) => { process.exit(r.statusCode === 200 ? 0 : 1) })"

EXPOSE 3000

CMD ["node", "dist/index.js"]

Advanced Multi-Stage Techniques

For Python/ML Applications:

 Copy
# Build stage with full conda environment
FROM continuumio/miniconda3:latest AS builder
WORKDIR /build
COPY environment.yml .
RUN conda env create -f environment.yml && \
    conda clean -afy

# Production stage with minimal runtime
FROM python:3.11-slim
COPY --from=builder /opt/conda/envs/myenv /opt/conda/envs/myenv
ENV PATH="/opt/conda/envs/myenv/bin:$PATH"
WORKDIR /app
COPY . .
CMD ["python", "app.py"]

Key Lessons:

• Always use specific version tags, never latest
• Order layers by change frequency (dependencies before code)
• Use .dockerignore aggressively (node_modules, .git, tests, etc.)
• Consider distroless or scratch images for maximum security

Security-First Container Design {#security-first-design}

Security must be baked in from the start. Here's my battle-tested security stack:

1. Base Image Selection & Scanning

 Copy
# Use Trivy for vulnerability scanning
trivy image --severity HIGH,CRITICAL myapp:latest

# Use Grype for additional coverage
grype myapp:latest

# Integrate into CI/CD
docker build -t myapp:${CI_COMMIT_SHA} .
trivy image --exit-code 1 --severity CRITICAL myapp:${CI_COMMIT_SHA}

Tool Selection (2025):

• Trivy: Best open-source scanner, fast, comprehensive (OS packages + app dependencies)
• Grype: Excellent SBOM-driven scanning
• Snyk: Enterprise choice with fix suggestions and CI/CD integrations
• Docker Scout: Native Docker integration, real-time insights

2. Non-Root User Pattern

 Copy
# WRONG - Running as root
FROM ubuntu:22.04
COPY app /app
CMD ["/app/server"]

# CORRECT - Non-root with proper permissions
FROM ubuntu:22.04

RUN groupadd -r appuser && \
    useradd -r -g appuser -u 1001 appuser && \
    mkdir /app && \
    chown -R appuser:appuser /app

COPY --chown=appuser:appuser app /app

USER appuser
WORKDIR /app

CMD ["./server"]

3. Read-Only Root Filesystem

 Copy
# docker-compose.yml
services:
  api:
    image: myapp:latest
    read_only: true
    tmpfs:
      - /tmp:noexec,nosuid,size=100m
    volumes:
      - ./data:/app/data
    security_opt:
      - no-new-privileges:true
    cap_drop:
      - ALL
    cap_add:
      - NET_BIND_SERVICE

4. Secrets Management

NEVER do this:

 Copy
# WRONG!
ENV DB_PASSWORD=mysecretpassword
ENV API_KEY=abc123

Production Pattern:

 Copy
# Using Docker Swarm secrets
version: '3.8'
services:
  app:
    image: myapp:latest
    environment:
      - NODE_ENV=production
      - DATABASE_URL_FILE=/run/secrets/db_url
    secrets:
      - db_url
      - api_key
    deploy:
      replicas: 3

secrets:
  db_url:
    external: true
  api_key:
    external: true

For Kubernetes:

 Copy
apiVersion: v1
kind: Secret
metadata:
  name: app-secrets
type: Opaque
stringData:
  database-url: "postgresql://..."
  api-key: "..."
---
apiVersion: apps/v1
kind: Deployment
metadata:
  name: myapp
spec:
  template:
    spec:
      containers:
      - name: app
        envFrom:
        - secretRef:
            name: app-secrets

Enterprise Pattern: Use External Secret Managers

 Copy
# Using External Secrets Operator
apiVersion: external-secrets.io/v1beta1
kind: SecretStore
metadata:
  name: vault-backend
spec:
  provider:
    vault:
      server: "https://vault.company.com"
      auth:
        kubernetes:
          mountPath: "kubernetes"
---
apiVersion: external-secrets.io/v1beta1
kind: ExternalSecret
metadata:
  name: app-secrets
spec:
  secretStoreRef:
    name: vault-backend
  target:
    name: app-secrets
  data:
  - secretKey: database-url
    remoteRef:
      key: secret/data/app/database
      property: url

5. Image Signing & Verification

 Copy
# Sign images with Cosign (2025 standard)
cosign sign --key cosign.key myregistry/myapp:v1.0

# Verify before deployment
cosign verify --key cosign.pub myregistry/myapp:v1.0

Health Checks and Self-Healing {#health-checks}

Proper health checks are the difference between 99.9% and 99.99% uptime.

Dockerfile Health Checks

 Copy
# Basic HTTP health check
HEALTHCHECK --interval=30s --timeout=3s --start-period=40s --retries=3 \
    CMD wget --no-verbose --tries=1 --spider http://localhost:3000/health || exit 1

# Advanced health check with dependencies
HEALTHCHECK --interval=30s --timeout=10s --start-period=60s --retries=3 \
    CMD curl -f http://localhost:8080/health/ready || exit 1

Application-Level Health Endpoints

 Copy
// Express.js health check pattern
const express = require('express');
const app = express();

let isReady = false;

// Liveness: Is the application running?
app.get('/health/live', (req, res) => {
  res.status(200).json({ status: 'alive', timestamp: Date.now() });
});

// Readiness: Is the application ready to serve traffic?
app.get('/health/ready', async (req, res) => {
  try {
    // Check database connection
    await db.ping();
    // Check Redis connection
    await redis.ping();
    // Check external API dependencies
    await checkExternalServices();

    res.status(200).json({
      status: 'ready',
      timestamp: Date.now(),
      dependencies: { db: 'ok', cache: 'ok', apis: 'ok' }
    });
  } catch (error) {
    res.status(503).json({
      status: 'not ready',
      error: error.message,
      timestamp: Date.now()
    });
  }
});

// Startup: Has initialization completed?
app.get('/health/startup', (req, res) => {
  if (isReady) {
    res.status(200).json({ status: 'started' });
  } else {
    res.status(503).json({ status: 'starting' });
  }
});

Kubernetes Probes (Production Pattern)

 Copy
apiVersion: apps/v1
kind: Deployment
metadata:
  name: myapp
spec:
  replicas: 3
  template:
    spec:
      containers:
      - name: app
        image: myapp:v1.0
        ports:
        - containerPort: 8080

        # Startup probe: Gives app time to initialize
        startupProbe:
          httpGet:
            path: /health/startup
            port: 8080
          failureThreshold: 30
          periodSeconds: 10

        # Liveness probe: Restart if unhealthy
        livenessProbe:
          httpGet:
            path: /health/live
            port: 8080
          initialDelaySeconds: 0
          periodSeconds: 10
          timeoutSeconds: 5
          failureThreshold: 3

        # Readiness probe: Remove from service if not ready
        readinessProbe:
          httpGet:
            path: /health/ready
            port: 8080
          initialDelaySeconds: 5
          periodSeconds: 5
          timeoutSeconds: 3
          successThreshold: 1
          failureThreshold: 3

Critical Insight: Separate liveness from readiness. Liveness failures restart pods; readiness failures just remove them from load balancers. A dependency failure should affect readiness, not liveness.

Environment Configuration & Secrets {#configuration-management}

Configuration management makes or breaks production deployments. Here's the hierarchy I use:

Configuration Hierarchy

1. Secrets (never in code or config files)
2. Environment variables (deployment-specific)
3. Config files (mounted as volumes)
4. Application defaults (in code)

Docker Compose Production Pattern

 Copy
version: '3.8'

services:
  api:
    image: ${REGISTRY}/myapp:${VERSION}
    environment:
      - NODE_ENV=production
      - LOG_LEVEL=${LOG_LEVEL:-info}
      - DATABASE_URL=${DATABASE_URL}
    env_file:
      - .env.production
    secrets:
      - db_password
      - jwt_secret
    configs:
      - source: app_config
        target: /app/config/production.yml
    deploy:
      replicas: 3
      restart_policy:
        condition: on-failure
        delay: 5s
        max_attempts: 3
        window: 120s
      update_config:
        parallelism: 1
        delay: 10s
        failure_action: rollback
        monitor: 30s
      resources:
        limits:
          cpus: '2'
          memory: 2G
        reservations:
          cpus: '1'
          memory: 1G

secrets:
  db_password:
    external: true
  jwt_secret:
    external: true

configs:
  app_config:
    file: ./config/production.yml

Kubernetes ConfigMap + Secret Pattern

 Copy
apiVersion: v1
kind: ConfigMap
metadata:
  name: app-config
data:
  app.yml: |
    server:
      port: 8080
      timeout: 30s
    features:
      newFeature: true
    logging:
      level: info
---
apiVersion: apps/v1
kind: Deployment
spec:
  template:
    spec:
      containers:
      - name: app
        volumeMounts:
        - name: config
          mountPath: /app/config
          readOnly: true
        - name: secrets
          mountPath: /app/secrets
          readOnly: true
      volumes:
      - name: config
        configMap:
          name: app-config
      - name: secrets
        secret:
          secretName: app-secrets

Production Logging & Observability {#logging-observability}

Logging is not optional. Here's my production stack:

Structured Logging Pattern

 Copy
// Winston configuration for production
const winston = require('winston');
const { ElasticsearchTransport } = require('winston-elasticsearch');

const logger = winston.createLogger({
  level: process.env.LOG_LEVEL || 'info',
  format: winston.format.combine(
    winston.format.timestamp(),
    winston.format.errors({ stack: true }),
    winston.format.json()
  ),
  defaultMeta: {
    service: 'myapp',
    version: process.env.VERSION,
    environment: process.env.NODE_ENV
  },
  transports: [
    // Console for Docker logs
    new winston.transports.Console({
      format: winston.format.combine(
        winston.format.colorize(),
        winston.format.simple()
      )
    }),
    // Elasticsearch for centralized logging
    new ElasticsearchTransport({
      level: 'info',
      clientOpts: {
        node: process.env.ELASTICSEARCH_URL,
        auth: {
          username: process.env.ES_USER,
          password: process.env.ES_PASSWORD
        }
      }
    })
  ],
  exceptionHandlers: [
    new winston.transports.File({ filename: 'exceptions.log' })
  ],
  rejectionHandlers: [
    new winston.transports.File({ filename: 'rejections.log' })
  ]
});

// Request correlation middleware
app.use((req, res, next) => {
  req.id = req.headers['x-request-id'] || uuid.v4();
  req.logger = logger.child({ requestId: req.id });
  next();
});

Docker Logging Configuration

 Copy
# docker-compose.yml
services:
  api:
    image: myapp:latest
    logging:
      driver: "json-file"
      options:
        max-size: "10m"
        max-file: "3"
        labels: "service,environment"
    labels:
      service: "api"
      environment: "production"

Production Observability Stack (2025)

 Copy
version: '3.8'

services:
  # Application
  myapp:
    image: myapp:latest
    environment:
      - OTEL_EXPORTER_OTLP_ENDPOINT=http://otel-collector:4318
      - OTEL_SERVICE_NAME=myapp
      - OTEL_RESOURCE_ATTRIBUTES=environment=production,version=${VERSION}
    depends_on:
      - otel-collector

  # OpenTelemetry Collector
  otel-collector:
    image: otel/opentelemetry-collector-contrib:latest
    command: ["--config=/etc/otel-collector-config.yml"]
    volumes:
      - ./otel-collector-config.yml:/etc/otel-collector-config.yml
    ports:
      - "4317:4317"   # OTLP gRPC receiver
      - "4318:4318"   # OTLP HTTP receiver

  # Prometheus (Metrics)
  prometheus:
    image: prom/prometheus:latest
    volumes:
      - ./prometheus.yml:/etc/prometheus/prometheus.yml
      - prometheus-data:/prometheus
    ports:
      - "9090:9090"

  # Grafana (Visualization)
  grafana:
    image: grafana/grafana:latest
    environment:
      - GF_SECURITY_ADMIN_PASSWORD=secret
    volumes:
      - grafana-data:/var/lib/grafana
      - ./grafana/dashboards:/etc/grafana/provisioning/dashboards
      - ./grafana/datasources:/etc/grafana/provisioning/datasources
    ports:
      - "3000:3000"

  # Loki (Logs)
  loki:
    image: grafana/loki:latest
    ports:
      - "3100:3100"
    volumes:
      - ./loki-config.yml:/etc/loki/local-config.yml
      - loki-data:/loki

  # Tempo (Traces)
  tempo:
    image: grafana/tempo:latest
    command: [ "-config.file=/etc/tempo.yml" ]
    volumes:
      - ./tempo.yml:/etc/tempo.yml
      - tempo-data:/tmp/tempo

  # Jaeger (Alternative distributed tracing)
  jaeger:
    image: jaegertracing/all-in-one:latest
    environment:
      - COLLECTOR_OTLP_ENABLED=true
    ports:
      - "16686:16686"  # Jaeger UI
      - "14268:14268"  # Collector HTTP
      - "4317:4317"    # OTLP gRPC

volumes:
  prometheus-data:
  grafana-data:
  loki-data:
  tempo-data:

Application Instrumentation

 Copy
// OpenTelemetry instrumentation
const { NodeSDK } = require('@opentelemetry/sdk-node');
const { PrometheusExporter } = require('@opentelemetry/exporter-prometheus');
const { OTLPTraceExporter } = require('@opentelemetry/exporter-trace-otlp-http');

const sdk = new NodeSDK({
  traceExporter: new OTLPTraceExporter({
    url: process.env.OTEL_EXPORTER_OTLP_ENDPOINT + '/v1/traces',
  }),
  metricReader: new PrometheusExporter({
    port: 9464,
  }),
  serviceName: 'myapp',
});

sdk.start();

process.on('SIGTERM', () => {
  sdk.shutdown()
    .then(() => console.log('Tracing terminated'))
    .catch((error) => console.log('Error terminating tracing', error))
    .finally(() => process.exit(0));
});

Orchestration: Kubernetes vs Docker Swarm {#orchestration-choice}

The eternal question. Here's my decision framework after deploying both in production:

Decision Matrix

When to Choose Kubernetes

• Scale: Running 50+ services or 100+ containers
• Multi-cloud: Deploying across AWS, GCP, Azure
• Advanced patterns: Need service mesh, GitOps, custom operators
• Team expertise: Engineers familiar with K8s
• Ecosystem: Need Helm charts, operators, CNCF tools

When to Choose Docker Swarm

• Simplicity: Small team, straightforward deployment
• Docker-native: Already using Docker Compose
• Resource-constrained: Edge deployments, small clusters
• Quick deployment: Need to ship fast without K8s complexity
• Learning curve: Team new to orchestration

Docker Swarm Production Setup

 Copy
# Initialize swarm
docker swarm init --advertise-addr <MANAGER-IP>

# Add workers
docker swarm join --token <WORKER-TOKEN> <MANAGER-IP>:2377

# Deploy stack
docker stack deploy -c docker-compose.yml myapp

# Scale service
docker service scale myapp_api=5

# Rolling update
docker service update --image myapp:v2 myapp_api

# Monitor
docker service ls
docker service ps myapp_api

Kubernetes Production Setup (K3s for Edge/IoT)

 Copy
# Install K3s (lightweight K8s)
curl -sfL https://get.k3s.io | sh -

# Deploy application
kubectl apply -f deployment.yml

# Scale
kubectl scale deployment myapp --replicas=5

# Rolling update
kubectl set image deployment/myapp app=myapp:v2

# Monitor
kubectl get pods
kubectl top pods
kubectl logs -f deployment/myapp

Hybrid Approach: K3s/K8s at Edge, K8s in Cloud

 Copy
# Edge K3s cluster (resource-constrained)
apiVersion: v1
kind: Namespace
metadata:
  name: edge-production

---
apiVersion: apps/v1
kind: Deployment
metadata:
  name: edge-processor
  namespace: edge-production
spec:
  replicas: 2
  template:
    spec:
      containers:
      - name: processor
        image: myapp:edge
        resources:
          requests:
            memory: "128Mi"
            cpu: "100m"
          limits:
            memory: "256Mi"
            cpu: "200m"
      nodeSelector:
        node-role.kubernetes.io/edge: "true"
      tolerations:
      - key: "node-role.kubernetes.io/edge"
        operator: "Exists"
        effect: "NoSchedule"

Domain-Specific Deployments {#domain-specific}

Fullstack Applications {#fullstack}

Frontend + Backend + Database Pattern

 Copy
version: '3.8'

services:
  # Frontend (React/Next.js)
  frontend:
    build:
      context: ./frontend
      dockerfile: Dockerfile.prod
    ports:
      - "80:80"
      - "443:443"
    depends_on:
      - backend
    volumes:
      - ./nginx.conf:/etc/nginx/nginx.conf:ro
      - certbot-certs:/etc/letsencrypt
      - certbot-webroot:/var/www/certbot
    deploy:
      replicas: 2
      resources:
        limits:
          cpus: '0.5'
          memory: 256M

  # Backend (Node.js/Python/Go)
  backend:
    image: ${REGISTRY}/backend:${VERSION}
    environment:
      - NODE_ENV=production
      - DATABASE_URL=postgresql://postgres:5432/mydb
      - REDIS_URL=redis://redis:6379
    depends_on:
      - db
      - redis
    deploy:
      replicas: 3
      resources:
        limits:
          cpus: '1'
          memory: 1G
      restart_policy:
        condition: on-failure

  # Database (PostgreSQL)
  db:
    image: postgres:16-alpine
    environment:
      POSTGRES_PASSWORD_FILE: /run/secrets/db_password
    volumes:
      - postgres-data:/var/lib/postgresql/data
      - ./init.sql:/docker-entrypoint-initdb.d/init.sql
    secrets:
      - db_password
    deploy:
      placement:
        constraints:
          - node.labels.db == true

  # Cache (Redis)
  redis:
    image: redis:7-alpine
    command: redis-server --appendonly yes
    volumes:
      - redis-data:/data

  # Background Jobs (Celery/Bull)
  worker:
    image: ${REGISTRY}/backend:${VERSION}
    command: celery -A app.celery worker --loglevel=info
    depends_on:
      - redis
      - db
    deploy:
      replicas: 2

volumes:
  postgres-data:
  redis-data:
  certbot-certs:
  certbot-webroot:

secrets:
  db_password:
    external: true

Nginx Configuration for Production

 Copy
# nginx.conf
upstream backend {
    least_conn;
    server backend:8080 max_fails=3 fail_timeout=30s;
    server backend:8080 max_fails=3 fail_timeout=30s;
    server backend:8080 max_fails=3 fail_timeout=30s;
}

server {
    listen 80;
    server_name example.com www.example.com;

    # Redirect HTTP to HTTPS
    return 301 https://$host$request_uri;
}

server {
    listen 443 ssl http2;
    server_name example.com www.example.com;

    ssl_certificate /etc/letsencrypt/live/example.com/fullchain.pem;
    ssl_certificate_key /etc/letsencrypt/live/example.com/privkey.pem;

    # Modern SSL configuration
    ssl_protocols TLSv1.2 TLSv1.3;
    ssl_ciphers HIGH:!aNULL:!MD5;
    ssl_prefer_server_ciphers on;

    # Security headers
    add_header Strict-Transport-Security "max-age=31536000; includeSubDomains" always;
    add_header X-Frame-Options "SAMEORIGIN" always;
    add_header X-Content-Type-Options "nosniff" always;
    add_header X-XSS-Protection "1; mode=block" always;

    # Static files
    location /static {
        alias /usr/share/nginx/html/static;
        expires 1y;
        add_header Cache-Control "public, immutable";
    }

    # API proxy
    location /api {
        proxy_pass http://backend;
        proxy_set_header Host $host;
        proxy_set_header X-Real-IP $remote_addr;
        proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
        proxy_set_header X-Forwarded-Proto $scheme;
        proxy_connect_timeout 30s;
        proxy_send_timeout 30s;
        proxy_read_timeout 30s;
    }

    # SPA fallback
    location / {
        root /usr/share/nginx/html;
        try_files $uri $uri/ /index.html;
    }
}

AI/ML Model Serving {#ai-ml}

GPU-Accelerated ML Deployment

 Copy
# Dockerfile for PyTorch/TensorFlow with GPU
FROM nvidia/cuda:12.1.0-cudnn8-runtime-ubuntu22.04

# Install Python and dependencies
RUN apt-get update && apt-get install -y \
    python3.11 \
    python3-pip \
    && rm -rf /var/lib/apt/lists/*

WORKDIR /app

# Install ML frameworks
COPY requirements.txt .
RUN pip3 install --no-cache-dir -r requirements.txt

# Copy model and application
COPY models/ ./models/
COPY app.py .

# Non-root user
RUN useradd -m -u 1001 mluser && \
    chown -R mluser:mluser /app
USER mluser

# Expose API
EXPOSE 8000

# Run with Gunicorn + Uvicorn workers
CMD ["gunicorn", "app:app", \
     "--workers", "4", \
     "--worker-class", "uvicorn.workers.UvicornWorker", \
     "--bind", "0.0.0.0:8000", \
     "--timeout", "120"]

Kubernetes ML Deployment with GPU

 Copy
apiVersion: apps/v1
kind: Deployment
metadata:
  name: ml-inference
spec:
  replicas: 2
  template:
    spec:
      containers:
      - name: model-server
        image: myregistry/ml-model:v1.0
        ports:
        - containerPort: 8000
        resources:
          requests:
            memory: "4Gi"
            cpu: "2"
            nvidia.com/gpu: 1
          limits:
            memory: "8Gi"
            cpu: "4"
            nvidia.com/gpu: 1
        env:
        - name: MODEL_PATH
          value: "/models/my-model"
        - name: BATCH_SIZE
          value: "32"
        volumeMounts:
        - name: models
          mountPath: /models
          readOnly: true
        livenessProbe:
          httpGet:
            path: /health
            port: 8000
          initialDelaySeconds: 60
          periodSeconds: 30
        readinessProbe:
          httpGet:
            path: /ready
            port: 8000
          initialDelaySeconds: 30
          periodSeconds: 10
      volumes:
      - name: models
        persistentVolumeClaim:
          claimName: model-storage
      nodeSelector:
        accelerator: nvidia-tesla-t4
      tolerations:
      - key: nvidia.com/gpu
        operator: Exists
        effect: NoSchedule

FastAPI ML Serving Pattern

 Copy
from fastapi import FastAPI, HTTPException
from pydantic import BaseModel
import torch
import numpy as np
from typing import List
import logging

app = FastAPI()

# Load model at startup
model = None

@app.on_event("startup")
async def load_model():
    global model
    model = torch.load('/models/my-model.pth')
    model.eval()
    logging.info("Model loaded successfully")

class PredictionRequest(BaseModel):
    data: List[List[float]]

class PredictionResponse(BaseModel):
    predictions: List[float]
    confidence: List[float]

@app.post("/predict", response_model=PredictionResponse)
async def predict(request: PredictionRequest):
    try:
        input_tensor = torch.tensor(request.data, dtype=torch.float32)
        with torch.no_grad():
            output = model(input_tensor)
            predictions = output.argmax(dim=1).tolist()
            confidence = torch.softmax(output, dim=1).max(dim=1).values.tolist()

        return PredictionResponse(
            predictions=predictions,
            confidence=confidence
        )
    except Exception as e:
        logging.error(f"Prediction error: {e}")
        raise HTTPException(status_code=500, detail=str(e))

@app.get("/health")
async def health():
    return {"status": "healthy", "model_loaded": model is not None}

@app.get("/metrics")
async def metrics():
    # Prometheus metrics endpoint
    return {"requests_total": 1000, "avg_latency_ms": 45}

MLOps Pipeline with Model Registry

 Copy
version: '3.8'

services:
  # MLflow for experiment tracking
  mlflow:
    image: ghcr.io/mlflow/mlflow:latest
    command: mlflow server --host 0.0.0.0 --backend-store-uri postgresql://mlflow:password@db:5432/mlflow --default-artifact-root s3://mlflow-artifacts
    ports:
      - "5000:5000"
    environment:
      - AWS_ACCESS_KEY_ID=${AWS_ACCESS_KEY_ID}
      - AWS_SECRET_ACCESS_KEY=${AWS_SECRET_ACCESS_KEY}
    depends_on:
      - db

  # Model serving
  model-server:
    image: myregistry/ml-model:${MODEL_VERSION}
    environment:
      - MLFLOW_TRACKING_URI=http://mlflow:5000
      - MODEL_NAME=my-production-model
      - MODEL_STAGE=Production
    depends_on:
      - mlflow
    deploy:
      replicas: 3
      resources:
        limits:
          nvidia.com/gpu: 1

IoT & Edge Computing {#iot-edge}

Edge Deployment with K3s

 Copy
# Dockerfile for ARM64 edge devices
FROM arm64v8/python:3.11-slim

# Install system dependencies
RUN apt-get update && apt-get install -y \
    build-essential \
    libgpiod2 \
    && rm -rf /var/lib/apt/lists/*

WORKDIR /app

COPY requirements.txt .
RUN pip install --no-cache-dir -r requirements.txt

COPY . .

# Run with resource constraints
CMD ["python3", "edge_processor.py"]

IoT Stack with MQTT

 Copy
version: '3.8'

services:
  # MQTT Broker (Eclipse Mosquitto)
  mqtt:
    image: eclipse-mosquitto:2
    ports:
      - "1883:1883"
      - "9001:9001"
    volumes:
      - ./mosquitto.conf:/mosquitto/config/mosquitto.conf
      - mosquitto-data:/mosquitto/data
      - mosquitto-logs:/mosquitto/log

  # IoT Gateway
  gateway:
    image: myregistry/iot-gateway:latest
    environment:
      - MQTT_BROKER=mqtt://mqtt:1883
      - DEVICE_ID=${DEVICE_ID}
      - CLOUD_ENDPOINT=${CLOUD_ENDPOINT}
    depends_on:
      - mqtt
    devices:
      - "/dev/ttyUSB0:/dev/ttyUSB0"
    privileged: true
    deploy:
      resources:
        limits:
          cpus: '0.5'
          memory: 256M

  # Edge Analytics
  analytics:
    image: myregistry/edge-analytics:latest
    environment:
      - MQTT_BROKER=mqtt://mqtt:1883
      - INFLUXDB_URL=http://influxdb:8086
    depends_on:
      - mqtt
      - influxdb

  # Time-series Database
  influxdb:
    image: influxdb:2.7-alpine
    ports:
      - "8086:8086"
    volumes:
      - influxdb-data:/var/lib/influxdb2
    environment:
      - INFLUXDB_DB=iot_data
      - INFLUXDB_HTTP_AUTH_ENABLED=true

  # Grafana for visualization
  grafana:
    image: grafana/grafana:latest
    ports:
      - "3000:3000"
    volumes:
      - grafana-data:/var/lib/grafana
    depends_on:
      - influxdb

volumes:
  mosquitto-data:
  mosquitto-logs:
  influxdb-data:
  grafana-data:

Edge Computing Best Practices

 Copy
# edge_processor.py - Optimized for resource-constrained devices
import paho.mqtt.client as mqtt
import json
import logging
from collections import deque
import time

class EdgeProcessor:
    def __init__(self):
        self.mqtt_client = mqtt.Client()
        self.buffer = deque(maxlen=1000)  # Circular buffer
        self.batch_size = 100
        self.last_upload = time.time()

    def process_sensor_data(self, data):
        # Edge processing: Filter noise, aggregate, compress
        if self.is_valid(data):
            processed = self.preprocess(data)
            self.buffer.append(processed)

            # Batch upload to cloud
            if len(self.buffer) >= self.batch_size or \
               time.time() - self.last_upload > 300:  # 5 min
                self.upload_batch()

    def preprocess(self, data):
        # Run lightweight inference on edge
        return {
            'timestamp': data['timestamp'],
            'value': data['value'],
            'anomaly': self.detect_anomaly(data['value'])
        }

    def upload_batch(self):
        if self.buffer:
            batch = list(self.buffer)
            self.mqtt_client.publish('cloud/data', json.dumps(batch))
            self.buffer.clear()
            self.last_upload = time.time()

Robotics Systems (ROS/ROS2) {#robotics}

ROS2 Docker Deployment

 Copy
# Dockerfile for ROS2 Humble
FROM ros:humble-ros-base-jammy

# Install dependencies
RUN apt-get update && apt-get install -y \
    ros-humble-navigation2 \
    ros-humble-slam-toolbox \
    ros-humble-robot-localization \
    python3-colcon-common-extensions \
    && rm -rf /var/lib/apt/lists/*

WORKDIR /ros2_ws

# Copy workspace
COPY src/ src/

# Build ROS2 workspace
RUN . /opt/ros/humble/setup.sh && \
    colcon build --symlink-install --cmake-args -DCMAKE_BUILD_TYPE=Release

# Setup entrypoint
COPY ./ros_entrypoint.sh /
RUN chmod +x /ros_entrypoint.sh

ENTRYPOINT ["/ros_entrypoint.sh"]
CMD ["ros2", "launch", "my_robot", "robot.launch.py"]

Multi-Robot Fleet Management

 Copy
version: '3.8'

services:
  # ROS Master / Discovery Server
  ros2-discovery:
    image: ros:humble
    command: ros2 daemon start
    network_mode: host
    environment:
      - ROS_DOMAIN_ID=0

  # Robot 1
  robot1:
    image: myregistry/robot:v1.0
    environment:
      - ROBOT_ID=robot1
      - ROS_DOMAIN_ID=0
      - ROBOT_NAMESPACE=/robot1
    devices:
      - /dev/video0:/dev/video0
      - /dev/ttyACM0:/dev/ttyACM0
    privileged: true
    network_mode: host

  # Robot 2
  robot2:
    image: myregistry/robot:v1.0
    environment:
      - ROBOT_ID=robot2
      - ROS_DOMAIN_ID=0
      - ROBOT_NAMESPACE=/robot2
    devices:
      - /dev/video1:/dev/video1
      - /dev/ttyACM1:/dev/ttyACM1
    privileged: true
    network_mode: host

  # Fleet Manager
  fleet-manager:
    image: myregistry/fleet-manager:latest
    ports:
      - "8080:8080"
    environment:
      - ROS_DOMAIN_ID=0
    network_mode: host
    depends_on:
      - ros2-discovery

  # Visualization (RViz)
  rviz:
    image: myregistry/robot:v1.0
    command: ros2 run rviz2 rviz2
    environment:
      - DISPLAY=$DISPLAY
      - ROS_DOMAIN_ID=0
    volumes:
      - /tmp/.X11-unix:/tmp/.X11-unix:rw
    network_mode: host

Scaling Architecture Patterns {#scaling-patterns}

Horizontal Pod Autoscaling (HPA)

 Copy
apiVersion: autoscaling/v2
kind: HorizontalPodAutoscaler
metadata:
  name: myapp-hpa
spec:
  scaleTargetRef:
    apiVersion: apps/v1
    kind: Deployment
    name: myapp
  minReplicas: 3
  maxReplicas: 20
  metrics:
  - type: Resource
    resource:
      name: cpu
      target:
        type: Utilization
        averageUtilization: 70
  - type: Resource
    resource:
      name: memory
      target:
        type: Utilization
        averageUtilization: 80
  - type: Pods
    pods:
      metric:
        name: http_requests_per_second
      target:
        type: AverageValue
        averageValue: "1000"
  behavior:
    scaleDown:
      stabilizationWindowSeconds: 300
      policies:
      - type: Percent
        value: 50
        periodSeconds: 60
    scaleUp:
      stabilizationWindowSeconds: 0
      policies:
      - type: Percent
        value: 100
        periodSeconds: 30
      - type: Pods
        value: 4
        periodSeconds: 30
      selectPolicy: Max

Vertical Pod Autoscaling (VPA)

 Copy
apiVersion: autoscaling.k8s.io/v1
kind: VerticalPodAutoscaler
metadata:
  name: myapp-vpa
spec:
  targetRef:
    apiVersion: "apps/v1"
    kind: Deployment
    name: myapp
  updatePolicy:
    updateMode: "Auto"
  resourcePolicy:
    containerPolicies:
    - containerName: '*'
      minAllowed:
        cpu: 100m
        memory: 128Mi
      maxAllowed:
        cpu: 4
        memory: 8Gi
      controlledResources: ["cpu", "memory"]

Cluster Autoscaling (Cloud Providers)

 Copy
# AWS EKS Node Group with autoscaling
apiVersion: eksctl.io/v1alpha5
kind: ClusterConfig
metadata:
  name: production-cluster
  region: us-west-2

managedNodeGroups:
  - name: general-purpose
    instanceType: t3.xlarge
    minSize: 3
    maxSize: 10
    desiredCapacity: 5
    volumeSize: 100
    ssh:
      allow: false
    labels:
      role: general
    tags:
      nodegroup-role: general
    iam:
      withAddonPolicies:
        autoScaler: true
        cloudWatch: true
        ebs: true

  - name: gpu-nodes
    instanceType: g4dn.xlarge
    minSize: 0
    maxSize: 5
    desiredCapacity: 0
    volumeSize: 200
    labels:
      accelerator: nvidia-tesla-t4
    taints:
      - key: nvidia.com/gpu
        value: "true"
        effect: NoSchedule

Service Mesh for Advanced Traffic Management

 Copy
# Istio VirtualService for canary deployment
apiVersion: networking.istio.io/v1beta1
kind: VirtualService
metadata:
  name: myapp
spec:
  hosts:
  - myapp.example.com
  http:
  - match:
    - headers:
        user-agent:
          regex: ".*Mobile.*"
    route:
    - destination:
        host: myapp
        subset: v2
      weight: 100
  - route:
    - destination:
        host: myapp
        subset: v1
      weight: 90
    - destination:
        host: myapp
        subset: v2
      weight: 10
---
apiVersion: networking.istio.io/v1beta1
kind: DestinationRule
metadata:
  name: myapp
spec:
  host: myapp
  trafficPolicy:
    connectionPool:
      tcp:
        maxConnections: 100
      http:
        http1MaxPendingRequests: 50
        http2MaxRequests: 100
    outlierDetection:
      consecutiveErrors: 5
      interval: 30s
      baseEjectionTime: 30s
      maxEjectionPercent: 50
  subsets:
  - name: v1
    labels:
      version: v1
  - name: v2
    labels:
      version: v2

Database Scaling Patterns

 Copy
# PostgreSQL with replication
version: '3.8'

services:
  postgres-primary:
    image: postgres:16-alpine
    environment:
      POSTGRES_PASSWORD_FILE: /run/secrets/db_password
      POSTGRES_REPLICATION_MODE: master
      POSTGRES_REPLICATION_USER: replicator
      POSTGRES_REPLICATION_PASSWORD_FILE: /run/secrets/repl_password
    volumes:
      - postgres-primary-data:/var/lib/postgresql/data
    deploy:
      placement:
        constraints:
          - node.labels.db.primary == true

  postgres-replica1:
    image: postgres:16-alpine
    environment:
      POSTGRES_PASSWORD_FILE: /run/secrets/db_password
      POSTGRES_REPLICATION_MODE: slave
      POSTGRES_MASTER_SERVICE: postgres-primary
      POSTGRES_REPLICATION_USER: replicator
      POSTGRES_REPLICATION_PASSWORD_FILE: /run/secrets/repl_password
    volumes:
      - postgres-replica1-data:/var/lib/postgresql/data
    depends_on:
      - postgres-primary

  # Read-only connection pooler
  pgbouncer:
    image: pgbouncer/pgbouncer:latest
    environment:
      - DATABASES_HOST=postgres-primary
      - DATABASES_PORT=5432
      - DATABASES_DBNAME=mydb
      - PGBOUNCER_POOL_MODE=transaction
      - PGBOUNCER_MAX_CLIENT_CONN=1000
      - PGBOUNCER_DEFAULT_POOL_SIZE=25
    ports:
      - "6432:6432"

CI/CD Integration & GitOps {#cicd-gitops}

GitHub Actions CI/CD Pipeline

 Copy
# .github/workflows/deploy.yml
name: Build and Deploy

on:
  push:
    branches: [ main, develop ]
  pull_request:
    branches: [ main ]

env:
  REGISTRY: ghcr.io
  IMAGE_NAME: ${{ github.repository }}

jobs:
  test:
    runs-on: ubuntu-latest
    steps:
      - uses: actions/checkout@v4

      - name: Run tests
        run: |
          docker compose -f docker-compose.test.yml up --abort-on-container-exit
          docker compose -f docker-compose.test.yml down

  security-scan:
    runs-on: ubuntu-latest
    steps:
      - uses: actions/checkout@v4

      - name: Build image
        run: docker build -t ${{ env.IMAGE_NAME}}:${{ github.sha }} .

      - name: Run Trivy vulnerability scanner
        uses: aquasecurity/trivy-action@master
        with:
          image-ref: ${{ env.IMAGE_NAME }}:${{ github.sha }}
          format: 'sarif'
          output: 'trivy-results.sarif'
          severity: 'CRITICAL,HIGH'
          exit-code: '1'

      - name: Upload Trivy results to GitHub Security
        uses: github/codeql-action/upload-sarif@v2
        if: always()
        with:
          sarif_file: 'trivy-results.sarif'

  build-and-push:
    needs: [test, security-scan]
    runs-on: ubuntu-latest
    permissions:
      contents: read
      packages: write
    steps:
      - uses: actions/checkout@v4

      - name: Log in to Container Registry
        uses: docker/login-action@v3
        with:
          registry: ${{ env.REGISTRY }}
          username: ${{ github.actor }}
          password: ${{ secrets.GITHUB_TOKEN }}

      - name: Extract metadata
        id: meta
        uses: docker/metadata-action@v5
        with:
          images: ${{ env.REGISTRY }}/${{ env.IMAGE_NAME }}
          tags: |
            type=ref,event=branch
            type=ref,event=pr
            type=semver,pattern={{version}}
            type=semver,pattern={{major}}.{{minor}}
            type=sha,prefix={{branch}}-

      - name: Build and push Docker image
        uses: docker/build-push-action@v5
        with:
          context: .
          push: true
          tags: ${{ steps.meta.outputs.tags }}
          labels: ${{ steps.meta.outputs.labels }}
          cache-from: type=gha
          cache-to: type=gha,mode=max

      - name: Sign image with Cosign
        run: |
          cosign sign --yes ${{ env.REGISTRY }}/${{ env.IMAGE_NAME }}@${{ steps.build.outputs.digest }}
        env:
          COSIGN_EXPERIMENTAL: "true"

  deploy-staging:
    needs: build-and-push
    if: github.ref == 'refs/heads/develop'
    runs-on: ubuntu-latest
    environment: staging
    steps:
      - name: Deploy to staging
        run: |
          kubectl set image deployment/myapp \
            app=${{ env.REGISTRY }}/${{ env.IMAGE_NAME }}:develop-${{ github.sha }} \
            --namespace=staging

  deploy-production:
    needs: build-and-push
    if: github.ref == 'refs/heads/main'
    runs-on: ubuntu-latest
    environment: production
    steps:
      - name: Deploy to production
        run: |
          kubectl set image deployment/myapp \
            app=${{ env.REGISTRY }}/${{ env.IMAGE_NAME }}:${{ github.sha }} \
            --namespace=production

      - name: Wait for rollout
        run: |
          kubectl rollout status deployment/myapp --namespace=production --timeout=5m

      - name: Run smoke tests
        run: |
          curl -f https://api.example.com/health || (kubectl rollout undo deployment/myapp --namespace=production && exit 1)

GitOps with ArgoCD

 Copy
# argocd-application.yaml
apiVersion: argoproj.io/v1alpha1
kind: Application
metadata:
  name: myapp
  namespace: argocd
spec:
  project: default

  source:
    repoURL: https://github.com/myorg/myapp-k8s-manifests
    targetRevision: HEAD
    path: overlays/production
    kustomize:
      images:
      - myregistry/myapp:v1.2.3

  destination:
    server: https://kubernetes.default.svc
    namespace: production

  syncPolicy:
    automated:
      prune: true
      selfHeal: true
      allowEmpty: false
    syncOptions:
    - CreateNamespace=true
    - PrunePropagationPolicy=foreground
    - PruneLast=true
    retry:
      limit: 5
      backoff:
        duration: 5s
        factor: 2
        maxDuration: 3m

  revisionHistoryLimit: 10

Blue-Green Deployment Strategy

 Copy
# Blue-Green with Kubernetes
apiVersion: v1
kind: Service
metadata:
  name: myapp
spec:
  selector:
    app: myapp
    version: blue  # Switch to 'green' for deployment
  ports:
  - port: 80
    targetPort: 8080
---
apiVersion: apps/v1
kind: Deployment
metadata:
  name: myapp-blue
spec:
  replicas: 3
  selector:
    matchLabels:
      app: myapp
      version: blue
  template:
    metadata:
      labels:
        app: myapp
        version: blue
    spec:
      containers:
      - name: app
        image: myapp:v1.0
---
apiVersion: apps/v1
kind: Deployment
metadata:
  name: myapp-green
spec:
  replicas: 3
  selector:
    matchLabels:
      app: myapp
      version: green
  template:
    metadata:
      labels:
        app: myapp
        version: green
    spec:
      containers:
      - name: app
        image: myapp:v2.0

Monitoring & Troubleshooting {#monitoring}

Prometheus Monitoring Setup

 Copy
# prometheus.yml
global:
  scrape_interval: 15s
  evaluation_interval: 15s

alerting:
  alertmanagers:
  - static_configs:
    - targets:
      - alertmanager:9093

rule_files:
  - /etc/prometheus/alerts/*.yml

scrape_configs:
  - job_name: 'prometheus'
    static_configs:
    - targets: ['localhost:9090']

  - job_name: 'docker'
    docker_sd_configs:
    - host: unix:///var/run/docker.sock
    relabel_configs:
    - source_labels: [__meta_docker_container_name]
      target_label: container

  - job_name: 'kubernetes-pods'
    kubernetes_sd_configs:
    - role: pod
    relabel_configs:
    - source_labels: [__meta_kubernetes_pod_annotation_prometheus_io_scrape]
      action: keep
      regex: true
    - source_labels: [__meta_kubernetes_pod_annotation_prometheus_io_path]
      action: replace
      target_label: __metrics_path__
      regex: (.+)
    - source_labels: [__address__, __meta_kubernetes_pod_annotation_prometheus_io_port]
      action: replace
      regex: ([^:]+)(?::\d+)?;(\d+)
      replacement: $1:$2
      target_label: __address__
